Hydrogen purity analyzer with gas range of 0-100%vol for power plant use
| Place of Origin | Henan, China |
|---|---|
| Brand Name | Chicheng |
| Certification | CE |
| Model Number | PH2-M |
| Price | $4,200.00/Units 1-4 Units |
| Packaging Details | Aluninum box |
| Customized Support | OEM, ODM | Product | Hydrogen Purity Analyzer |
|---|---|---|---|
| Model | PH2-M | Color | Grey |
| Power Supply | AC220V ,back Up Battery | Material | Engineering Material |
| Screen | LCD | Gas | Hydrogen |
| Data Logging | 50 | Sensor | International Brand |
| Size(L*W*H) | 258*240*88mm |
Hydrogen purity analyzer with gas range of 0-100%vol for power plant use
PH2-M is a special hydrogen purity analyzer,analyzing the hydrogen gas purity from the hydrogen cooled generator. The analyzer adopts the original sensor from H1-P(HL Planartechnik in German) and manufactured in our factory. This analyzer detects the hydrogen directly when the airway tubeis connected on -site, without sampling in advance .
The original"absorption method" detecting the hydrogen has many problems:complex operation, occupiedmuch time and workers, its accuracy is upon the worker's operation and the absorption method can not reflect the displacing process.
Compared to the original"absorption method",PH2-M with rechargeable battery inside,is smart light,stable,swift response and easy to operate. And it has good accuracy(accuracy is better than 1%) and linear.
Application: it is widely applied to detect the hydrogen gas purity,especially in the generating plant for hydrogen cooled generator and hydrogen generator station,and it is used to monitor the hydrogen displacing process when the hydrogen cooled generator is switched on and off.
Features:
- Firm,long working life
- Swift response,good linear and stable read value.
- Built-in flow meter and flow control valve.
- Easy operation and calibration
- LCD display and picture menu.
Technical Data:
- Range:0-100% for hydrogen(h2) in CO2
- 0-100% for CO2 in the air
- 0-100% for hydrogen(h2) in the air
- 0-100% for air in CO2
- Accuracy:+0.1%F.S
- Repeatability:+0.1%F.S
- Linearity: +0.4%F.S
- Capacity: 50 records
- Output interface:USB1.1
- Temperature:-30-50
- Response:5-15s
- Constant pressure valve:0-1Mpa working
- Working pressure:0-1Map
- Electronic flowmeter: mass flometer 0-1000ml/min
- Air intake flow:20-200ml/min
- Detecting method: with temperature-compensation thermal conductivity method(Even there is no gas flow
- or the gas changed, the analyzer will be influenced)
- Power supply: AC220V 50Hz and built in rechargeable battery
- Weight:3.6kg
- Size:340*240*130mm
- Package: Aluminum box with foad inside
-Fast delivery:
Sample order in stock and 3-7 working days for bulk production.
-Payment:
You can pay for the order via T/T, Western Union, PayPal & Money Gram.
-Shipping:
We have strong cooperation with DHL, TNT, UPS, FEDEX, EMS, CHINA AIR POST.
You also can choose your own shipping forwarder.
1.Any inquiries will be replied within 24 hours.
2.Professional manufacturer.Welcome to visit our website.
3.OEM/ODM available
a. Customer brand(law allowance) can be made on the sticker.
b. Customized gas detection tools are welcomed
c. Customized color box.
d. Any your idea gas detection tool we can help you to design and put it into production
4.High quality ,fashion design,reasonable &competitive price,fast lead time.
5.After-sale service:
a.All products will have been strictly Quality Checked before packing.
b.All products will be well packed before shipping.
c.All our products have 1 year warranty.And we sure the product will be free from maintenance within warranty period.
