High accuracty portable ozone O3 gas leak detector with air samping pump
| Place of Origin | Henan, China |
|---|---|
| Brand Name | chicheng |
| Certification | CE |
| Model Number | GC510 |
| Price | $300.00 - $400.00/Sets |
| Packaging Details | each set will be packed with the export standard carton package or aluminum box. |
| Supply Ability | 5550 Set/Sets per Month portable O3 gas leak alarm |
| Customized Support | OEM, ODM | Detected Gas | O3 |
|---|---|---|---|
| Product Name | Portable O3 Gas Leak Detector | MOQ | 1 |
| Display | LCD | Accuracy | 3% F.S |
| Response Time | T90<30s | Power Supply | DC7.4V Rechargeable Li-ion Battery |
| Alarm Method | Flicker, Three Color LED Warning Lamp | Power Source | With Battery And Charger |
| Enclosure | Strong, Durable And Shockproof. | Port | Qingdao |
High accuracty portable ozone O3 gas leak detector with air samping pump
Product Description
High accuracty portable ozone O3 gas leak detector with air samping pump GC510 is a kind of gas detector which can detect toxic gas, combustible gas, oxygen gas, or vocs gas etc.
GC510 can be equipped with built-in air pump to extract air and test the air sample in the testing area, then transfer the air sample into the gas detector to test, which is with rapid detection speed. Long distance detection can be performed in the dangerous area to guarantee the worker’s safety.
Features
1.Small size, light weight and durable.
2.Adopt embedded 16-bit microprocessor, ensure that the product is in stable and reliable operation.
3.Visual, audible, vibration alarm.
4.Chinese or English menu is optional.
5.Large display screen, easy operation.
6.Self-test function.
7.1000 alarm records storage.
8.Save and restore the factory setting function.
9.Embedded air pump
Technical Specification
| Name and Model | Portable O3 gas detector |
| Sensor | Electrochemical gas sensor |
| Detected gas range | 0-100ppm |
| Resolution | 1ppm |
| Alert | LED lights with triple colors,buzzer with 90dB. |
| Response | T90 < 30s |
| Ambient environment | -10℃~+50℃;Humidity<90%RH No condensing |
| Power supply | DC 7.4V lithium battery,1800mAh |
| Dimension | l x b x h : 227×71×35(mm) |
| Weight | 450g |
Detailed illustration
| No. | Item | No. | Item |
| 1 | Inlet | 8 | Pageup |
| 2 | Thread sleeve | 9 | Upper shell |
| 3 | LED lights with triple colors | 10 | Mask |
| 4 | LCD | 11 | Outlet |
| 5 | Buzzer | 12 | USB |
| 6 | Menu | 13 | DC9V for charging |
| 7 | Power | 14 | Lower shell |
Company Information
1.More than 10 years industrial experience 2. ODM & OEM service
3. 3000 square meter factory 4. 10 production lines
5. 1-3 year warranty 6. 50 experience R&D engineers
Worldwide Fair & Visiting Customer
Certificates
Package & Shipping
1. Packaging:Standard Carton box or aluminum box
2. Delivery: Sample order in stock and 3-7 working days for bulk production.
3, Payment: You can pay for the order via T/T, Western Union, PayPal & Money Gram.
4. Shipping: DHL, TNT, UPS, FEDEX, EMS, CHINA AIR POST.
5. You can also choose your own shipping forwarder.
FAQ
1. Can I have a sample order?
A: Yes, we welcome sample order to test and check quality.
2. What is the lead time?
A: Sample needs 1-3 days, mass production time needs 7-15 days for order less than 5000 pcs.
3. Do you have any MOQ limit?
A: We don’t have a MOQ limit, 1 pc are also welcome.
4. Do you offer guarantee for the products?
A: Yes, we offer one or two year guarantee for the products.
5. Do you accept drop shipping?
A: Yes, it’s available.
6. What will your ODM&OEM service cover?
A: a. Customer brand and logo print (law allowed) can be made on the sticker.
b. Customized color and special function of gas detection tools.
c. Customized box.
d. Your other ideas about gas detection tools, we can help you design and put them into production.
e. Different language versions, such as English, Russian, Chinese, etc. according to customers requirement.
