High Accuracy Portable Ozone Gas Detector 0-10ppm ozone sensor

  High Accuracy Portable Ozone Gas Detector 0-100ppm ozone sensor

The portable ozone gas detector GC210 is used for environment measure to test the O3 generator. It gives alarm when O3 is up to a dangerous level in the air, or in the spaces such as gyms, sports centers. Please check its technical datasheet attached for your kind reference. And for this purpose, we suggest the middle range 0-10.0 or 20.0ppm ozone gas detector.

The O3 gas it's ideal disinfectant to clean the virus. Much spaces such as gyms, sports centers, meeting room etc adopt ozone generator to do disinfectant work.

O3 is helpful to do disinfectant work but itself is harmful to people health. When ozone disinfectant work is being done, it must be sure there is no person in that space and people are forridden to enter that space at least 30 minutes after disinfection. .

When the ozone concentration in the environment reaches 0.15ppm, it can be sniffed; when it reaches 0.5-1ppm, it can cause mouth dry and other discomfort. when it reaches 1--4ppm, it can cause cough, when it reaches 4-10ppm; it can cause strong cough

Application:

The detector monitors ozone gas density and is widely used in metallurgy, electric factory, chemical, mines, tunnels, underground pipes etc, effectively prevent toxic accident.

Features:

•  Reliable and durable fixed life by the imported sensor
•  Automatical calibration and zero-set
•  Apparent and Clear Display
• Chinese menu, displaying real time and battery capacity, low battery indication and automatic turn-off for low voltage
•  Rapid and effective warning with audible alarm, and extremely bright visual light alarm and vibrating alarm as standard.
• Advanced self-test of complete functions automatically when turned on
• 1000 record capacity
•  Alarm for sensor failure
•  Password management to avoid wrong operation;
•  Advanced self- calibration for accuracy.

• Gas Detected:ozone
• Range: 0-100ppm
• Resolution: 1 ppm
• Response time: T90<30s
• Indication: Large STN LCD indicates real time and system state
• Alarm indication: Wide-angled light emitting diode, 85db buzz(the frequency of buzz depends the density),vibrating.
• Fault indication: indications of Zero point drift and sensor failure.
• Operating temperature: -30 ~ + 50 degree
• Humidity:  lower than 95%RH non-condensing
• Voltage: DC3.7V Li-ion battery 1200mAh
• Charging time: 4h~6h
• Duration of operation: flammable gas no more than 8 (non-stopped); toxic gas no more than 300h(non-stopped).
• IP Grade: IP66.
• Weight: about 120g(including battery)
• Dimension: 102 mm×56mm×26mm.
