Underground pipeline inspection CO/O2/VOC/CH4 multi portable Gas Meter Detector
| Place of Origin | Henan, China |
|---|---|
| Brand Name | chicheng |
| Certification | CE |
| Model Number | GC310 |
| Price | $260.00 - $340.00/Sets |
| Packaging Details | in standard export carton package. |
| Supply Ability | 5000 Set/Sets per Month |
| Customized Support | OEM, ODM | Product Name | Pipeline Inspection Detector |
|---|---|---|---|
| Model | GC310 | Response Time | T90<30S |
| Alarm | Light And Audio | Calibration | Automatical |
| Sensor | Catalytic Combustion Sensor; Electrochemical Sensor;PID Sensor | Working Environment | -20--50℃ |
| Power Supply | 3.6V Li-ion Chargeable Battery Can Work 200 Hours | Size & Weight | 126*66*32; 220g |
| Explsion Grade | EX Ib II CT3 | Port | Qingdao, Tianjiin, Shanghai, Hong Kong Etc. |
Underground pipeline inspection CO/O2/VOC/CH4 multi portable Gas Meter Detector
Product description
GC310 is a flexible portable gas detector for multi-gases(up to 4 gases) leak detection. It can be set with original CITY catalytic combustion sensor for combustible gas, while original electro-chemical sensors for toxic gases and oxygen. The normal gases detected are CO, H2S, O2, LEL(CH4O)while it can be set to monitor other four gases. GC310 has large LCD screen and two instant alarms with audio/visual and vibratory indicators, making it a favorite indicator for operators working in demanding industrial environments.
Features:
- Compact, small and lightweight design
- wo instant alarms with audio/visual and vibratory indicators
- Large easy to read display of emblems, instantaneous value, peak value, TWA and STEL.
- Self test function: Self-testing upon start up or need for display, battery, sensor and alarm
- Warning Indicator: regular flashing light and audible alarm
- Up to 4 gases design
- English operation interface and English software
Applications:
- STEL and TWA monitoring;
- Atmosphere monitoring;
- Monitoring for cleanliness of environment;
- Petroleum and chemical plant;
- Entering of sealing space
- Quick respond for dangerous substance/ chemical weapon
- Industrial paints;
- Leakage detecting;
- IAQ monitoring of indoor air quality;
- Soil pollution monitoring
Technical specifications:
| Range | H2S:0-100ppm CO:0-999ppm, O2:0-30%VOL, Combustible gas(CH4O):0-100%LEL VOC:0.1-100/1-1000ppm |
| Calibration | Automatical calibration and zero |
| Sensor | Catalytic combustion type, electrochemical sensor (with temperature compensation), PID sensor |
| Responding | T90 < 30s |
| Alarms | Flashing wide-angled LED alarm light and LCD reading; 90dB impulse output |
| Display | LCD display of gas reading and condition, display TWA and peak value when needed |
| Ambient Environment | -20—50°C,5—90%RH(no condensation) |
| Power Supply | 3.6V Li-ion chargeable battery can work 200 hours |
| Enclosure | compact , durable ruggedised ABS shell |
| Size & Weight | 126×66×32(mm),220g |
| Explosion Grade | EX ibⅡCT3 |
Product details:
Company introduction
More than 10 years industrial experience
ODM & OEM service
1-3 year warranty
3000 square meter factory area
10 production lines
50 experience R&D engineers
International Fair and Visiting customers:
Aging area
Calibration Certificate:
Product overview of our company
Industrial use: Portable gas detectors, fixed gas detectors, gas leak automation control panel, etc
Domestic use: household gas detectors, smoke detectors, safety protection instrument, etc.
Packing and Delivery:
Packaging: Carton box or Aluminum box on your requirement
Delivery: Sample order in stock and 3-7 working days for bulk production.
Payment: You can pay for the order via T/T, Western Union, PayPal & Money Gram.
Shipping: DHL, TNT, UPS, FEDEX, EMS, CHINA AIR POST.
You can also choose your own shipping forwarder.
FAQ:
1. Can I have a sample order?
A: Yes, we welcome sample order to test and check quality.
2. What is the lead time?
A: Sample needs 1-3 days, mass production time needs 7-15 days for order less than 5000 pcs.
3. Do you have any MOQ limit?
A: We don’t have a MOQ limit, 1 pc are also welcome.
4. Do you offer guarantee for the products?
A: Yes, we offer one or two year guarantee for the products.
5. Do you accept drop shipping?
A: Yes, it’s available.
6. What will your ODM&OEM service cover?
A: a. Customer brand and logo print (law allowed) can be made on the sticker.
b. Customized color and special function of gas detection tools.
c. Customized box.
d. Your other ideas about gas detection tools, we can help you design and put them into production.
e. Different language versions, such as English, Russian, Chinese, etc. according to customers requirement.
7.How does your factory do regarding the quality control?
A: Quality is priority, regarding welding&cutting products. Our factory has passed ISO 9001 with annual audit.
Established a procedure to check products at all stages of the manufacturing process - raw materials, in process materials, validated or tested materials, finished goods, etc.
