GC210 Portable hydrogen sulfide detector alarm H2S monitor by factory price OEM support
| Place of Origin | Henan, China |
|---|---|
| Brand Name | chicheng |
| Certification | CE |
| Model Number | GC210 |
| Price | $120.00 - $200.00/Units |
| Packaging Details | STANDARD IN CARTON |
| Supply Ability | 50000 Piece/Pieces per Month |
| Customized Support | OEM, ODM | MOQ | 1 |
|---|---|---|---|
| Enslosure Color | Blue And Yellow | Alarm Ways | Sound, LED Alarm, Vibration |
| Battery | Inbuilt Rechargeable Lithium Battery | Ex-proof Grade | Ex Ia IIC T4 |
| Product Name | Portable H2S Gas Detector Hydrogen Sulfide Gas Sensor | Port | Shanghai, Qingdao Etc |
Portable hydrogen sulfide detector alarm
GC210-04 is a Portable Micro Clips Hydrogen Sulfide H2S Single Gas Detector with intrinsic safety ( detector hereinafter ) , which can continuously monitor toxic gas hydrogen sulfide(H2S) gas leak density. It is applied for toxic gas(H2S) leak detection, rescue, and also applied in the surroundings such as underground pipe and mine, to keep the workers safe from H2S concentration to save lives.. The detector monitors toxic gas(H2S) leak density by natural diffusion and adopts imported electro-chemical sensor, having good sensibility and excellent repeatability. The device has embedded micro control technique and simple signal display and English instruction menu, making the operation easy. Complete function and dependability makes the whole device a leader in the nation. The cover of the detector is refined from high-intensive engineering material (compound elastic rubber), which made the detector touches well, waterproof and explosion-protection.
Application:
The Portable Micro Clips Hydrogen Sulfide H2S Single Gas Detector monitors toxic gas(H2S) density and is widely used in metallurgy, electric factory, chemical, mines, tunnels, underground pipes etc, effectively prevent toxic accident.
Features:
1.Smart, light, compact, easy to carry
2.Reliable and durable fixed life by original imported sensor, and the sensor and battery is replacible
3.With temperature-compensation.
4.Three ways for alarm: audible alarm(>85db alterable sound alarm),visual alarm(wide-angled red and blue LED flash and visual from a distance), and vibration(various frequency alarm indicates different alarm grades in the noisy surroundings)
5. IP66 design for water- dust proof
6. Low, high alarm limit, TWA and STEL are adjustable.
7. Advanced self-test of complete functions automatically when switched on
8.Heartbeat detecting and with single lithium battery for 2 years normal work.
- Range: See attached table.
- Gas Detected:H2S
- Accuracy: 3% F.S
- Response time: T90<30s
- Indication: Large STN LCD indicates real time and system state
- Alarm indication: Wide-angled light emitting diode, 85db buzz(the frequency of buzz depends the density),vibrating.
- Fault indication: indications of Zero point drift and sensor failure.
- Operating temperature: -30 ~ + 50 degree
- Humidity:< 95%RH non-condensing
- Voltage: DC3.7V Li-ion battery 1200mAh
- Charging time: 4h~6h
- Duration of operation: flammable gas less than 8 (non-stopped); toxic gas less than 300h(non-stopped).
- IP Grade: IP66.
- Weight: about 120g(including battery)
- Dimension: 102 mm×56mm×26mm.
Established in 2004, Henan Chicheng Electronics Co.,Ltd is speclized in the R&D, manufacture, marketing of gas detector device in China, we can always supply you professional technical support and solutions.
With ISO9001-2000 Certified, Chicheng products are mainly divided into household gas alarm, portable single/multi gas detector, industrial fixed gas detecting transmitter, etc.
Henan Chicheng has a mission to offer proper device and excellent all-round services to customers from automotive production plants, petrochemical, gas, pharmaceutical and metallurgical industries.
Sincerely welcome customers worldwide. OEM and ODM welcome !
