220V/110v Smart home security gas leakage carbon monoxide natural gas detector alarm with display
| Place of Origin | Henan, China |
|---|---|
| Brand Name | CCE |
| Certification | CE |
| Model Number | HD1100D |
| Minimum Order Quantity | 10 Pieces |
| Price | $10.00 - $20.00/Pieces |
| Packaging Details | carton box. |
| Supply Ability | 3000 Set/Sets per Day |
| Network | NBiot | Product Name | Smart Home Security Gas Detector |
|---|---|---|---|
| Power | AC220V, AC110V, DC12V Or DC24V | Gas | All Combusitible Gas |
| Alarm Point | 7%LEL(CH4,LPG), 100ppm(CO) | Audible | >80dB |
| Working Environment | -10 °C~+55 °C | Humidity | <95% RH |
| Atmospheric Pressure | 86kpa~106kpa (indoor) | Size And Weight | 120 X 82 X 45 Mm, 250g |
| Port | China Main Ports |
HD1100 220V/110v Smart home security gas leakage carbon monoxide natural gas detector alarm with display
Domestics gas leakage detection product description
HD1100C is a new standalone AC powered plug-in coal gas detector to protect you and others from the dangers of coal gas(carbon monoxide). The detector is with LCD digital screen continuously displays the level of coal gas (if any) the alarm is sensing. The detector adopts MCU processing technology with a long life, convenient installation and high reliability. Besides, it completes with a special circuit that control the advanced electro-chemical sensor’s efficiency level, and signals any possible fault.
Domestics gas leakage detection product features
High reliability—Advanced electro-chemical sensor with
--Professional low profile design
--With special circuit(MCU processing control and SMT manufacture Technology).
-- Execute criterion: GB15322, EN50291, UL2034, EN50194
Easy to Install---Unit plugs directly into any wall outlet with power cord
Easy operation—Clearly visible status indications LEDS (power, preheat, fault and
alarm) and LCD digital display.
--Button for test and rest: Test the alarm electronics and reset the unit
during alarm.
--Loud 85dB at 1m
Low total cost—Ideal for easy installation
--Direct connection to a solenoid valve
--5 years working life with 2 year guarantee.
Designed for residential environments—Slim,small, compact design with stylish features, ideal for residential setting and modern decorations.
Domestics gas leakage detection technical specifications
| Model No. | HD1000 | HD1000-valve | HD1100-relay | HD1100-GPRS |
| Operating voltage | AC100V-240V | AC100V-240V | AC100V-240V | |
| Gas species | Natural Gas or LPG | |||
| Alarm value | ||||
| Alarm output | Sound &LED flash alarm | Relay output (NO)Sound &LED flash alarm | Relay output (NO)Sound &LED flash alarm | |
| Drivable accessories | N/A | Solenoid Valve | Solenoid valve and Exhaust fan | |
| Rated power | 2.5W | 2.5W | 2.5W | |
| Alarm level | 10%±5% LEL | |||
| Sound level | ≥85dB/3m | |||
| Installation | Wall mounted | |||
| Working environment | -10°c~+50°c(≤95%RH No congelation) | |||
| Dimension | 115*72*41mm | |||
| Weight | 250g | |||
| Lifetime | 5 Years | |||
| Warranty | 2 Years | |||
Domestics gas leakage detection product Applications
Company introduction
- More than 10 years industrial experience
ODM & OEM service
1-3 year warranty
-
3000 square meter factory area
10 production lines
50 experience R&D engineers
Product overview
Industrial use: Portable gas detectors, fixed gas detectors, gas leak automation control panel, etc
Domestic use: household gas detectors, smoke detectors, safety protection instrument, etc.
Domestics gas leakage detection Packing and Delivery
Delivery: Sample order in stock and 3-7 working days for bulk production.
Payment: You can pay for the order via T/T, Western Union, PayPal & Money Gram.
Shipping: DHL, TNT, UPS, FEDEX, EMS, CHINA AIR POST.
You can also choose your own shipping forwarder.
FAQ:
1. Can I have a sample order?
A: Yes, we welcome sample order to test and check quality.
2. What is the lead time?
A: Sample needs 1-3 days, mass production time needs 7-15 days for order less than 5000 pcs.
3. Do you have any MOQ limit?
A: We don’t have a MOQ limit, 1 pc are also welcome.
4. Do you offer guarantee for the products?
A: Yes, we offer one or two year guarantee for the products.
5. Do you accept drop shipping?
A: Yes, it’s available.
6. What will your ODM&OEM service cover?
A: a. Customer brand and logo print (law allowed) can be made on the sticker.
b. Customized color and special function of gas detection tools.
c. Customized box.
d. Your other ideas about gas detection tools, we can help you design and put them into production.
e. Different language versions, such as English, Russian, Chinese, etc. according to customers requirement.
